Precise radar alignment begins with the right mounting solution. The mounting bracket determines how accurately a sensor can detect, classify, and track objects in its field of view. At smartmicro, we offer two types of brackets designed to meet different installation needs: the Straight Bracket and the Advanced Bracket. Both ensure reliable and durable mounting, but they provide different levels of flexibility for alignment.
Why Mounting Precision Matters
Even the most advanced radar sensor can only perform to its full potential when it is properly aligned. A small deviation in angle can affect detection range and accuracy. Therefore, selecting the right bracket is essential to ensure the radar’s field of view is perfectly oriented toward the monitored area.
smartmicro brackets are made from robust, corrosion-resistant materials, engineered for long-term outdoor use. They maintain stable alignment in varying weather conditions, under vibration, and across a wide temperature range.
Straight Brackets
Simple and Reliable
The Straight Bracket is designed for installations where the mounting position itself can set the azimuth (horizontal direction). It allows adjustment of the elevation angle, enabling precise vertical alignment of the radar.
Key features:
- Compact and lightweight design
- Simple and quick to install
- Ideal for standard applications where only tilt adjustment is required
The Straight Bracket is an excellent choice for straightforward installations such as gantry or pole mounts, where the mounting direction already defines the radar orientation.
Advanced Brackets
Full Flexibility for Complex Setups
The Advanced Bracket provides complete flexibility in alignment. It allows adjustment in azimuth, elevation, and roll, which makes it suitable for complex or non-standard installations. Integrated angle scales enable precise and repeatable adjustment in all axes.
Key features:
- Adjustment of azimuth, elevation, and roll
- Built-in angle scales with 5° increments
- Compatible with both horizontal and vertical bar mounting
- Durable stainless-steel construction for long service life
The Advanced Bracket is ideal for situations where the mounting position cannot be perfectly aligned or where fine-tuning is required after installation.
Choosing the Right Bracket
Both bracket types provide the same radar performance. The difference lies in the alignment flexibility.
Choose the Straight Bracket when the installation allows you to set the azimuth in advance and only the tilt angle needs adjustment.
Choose the Advanced Bracket when the setup requires adjustment in multiple axes or when the mounting structure is not ideally positioned.
Built for Durability
All smartmicro brackets are made to withstand demanding environmental conditions. The high-quality materials ensure long-term resistance to corrosion and mechanical stress, guaranteeing consistent radar alignment over many years of operation.
Discover the Right Mounting Solution
Whether your project requires a simple, fixed installation or a fully adjustable setup, smartmicro provides the right bracket for every situation. Both types are designed with precision, longevity, and installation efficiency.
