PREMIUM LINE I TRUGRD
Radar sensors for traffic management
smartmicro’s TRURGD Premium Line of traffic sensors offers best-in-class detection for a wide range of traffic management applications. Learn more about each model and discover which one is the perfect choice for your use case.
Fail-Safe Features
Works under all weather conditions
Multi-lane, multi-object detection
Maintenance-free
Low power consumption
All sensors from the TRUGRD Line are 100% compatible with each other as well as all smartmicro accessories.
TRUGRD's operational frequency - 24GHz - is authorized to use worldwide and meets the requirements of a variety of local regulations.
Although the TRUGRD sensors meet the requirements of various applications, each one has a recommended use based on detection goal, location, and road infrastructure.
Meet THE Family
Scroll to: TRUGRD | TRUGRD Stream | TRUGRD LR | TRUGRD Lite
TRUGRD
TRUGRD outperforms competitors in accuracy and reliability. The sensor is ideal for intersection, highway management as well as enforcement applications. With a field of view of 110° the sensor can monitor up to 12 lanes and 256 objects simultaneously.
Recommended for:
TRUGRD Stream
3D/UHD+ RADAR TECHNOLOGY COMBINED WITH VIDEO
TRUGRD Stream is all-in-one solution combining the benefits of TRUGRD and video. Its integrated camera with supreme low-light performance streams live from the installation site and provides visualization for the user.
Recommended for:
TRUGRD LR
ULTRA-LONG RANGE SENSOR ENABLING HIGHWAY MANAGEMENT
Its 3D/UHD+ resolution provides the necessary detection quality and therefore helps to achieve the necessary safety standards of the system. With zero cleaning and no maintenance required, smartmicro’s TRUGRD LR offers the lowest possible lifecycle cost.
Recommended for:
TRUGRD Lite
Stop bar detection for North American intersections
TRUGRD Lite matches the needs for simple presence detection at the stop bar. TRUGRD Lite is the perfect solution for covering smaller intersections and side streets.
Available for the USA and Canada only.
Recommended for:
Model Comparison
| TRUGRD | TRUGRD Stream | TRUGRD LR | TRUGRD Lite* | ||
|---|---|---|---|---|---|
| Range | |||||
| Min. / Max. | 1.5m / 300m | 1.5m / 300m | 3m / 500m | 1.5m / 122m | |
| Separation | 2 or 4m | 2 or 4m | 4.8m | 2m | |
| Accuracy | ±0.25m | ±0.25m | ±0.5m | ±0.25m | |
| Speed | |||||
| Min. / Max. | -320…+320km/h | -320…+320km/h | -210…+210km/h | -210…+210km/h | |
| Separation | 0.23m/s | 0.23m/s | 0.24m/s | 0.23m/s | |
| Accuracy | < ±0.1m/s | < ±0.1m/s | < ±0.1m/s | < ±0.1m/s | |
| Angle | |||||
| Field of View: Azimuth | -55…+55° | -55…+55° | -20…+20° | -55…+55° | |
| Field of View: Elevation | -10…+10° | -10…+10° | -9…+9° | -10…+10° | |
| Separation: Azimuth | < 6° | < 6° | < 2.5° | < 6° | |
| Accuracy: Azimuth | < 0.5° | < 0.5° | < 0.25° | < 0.5° | |
| Mechanical | |||||
| Weight | ≤ 1290g | ≤ 1575g | ≤ 1290g | ≤ 1290g | |
| Dimensions | 212.6 x 154.6 x 31.65mm | 212.6 x 154.6 x 31.65mm** | 212.6 x 154.6 x 31.65mm | 212.6 x 154.6 x 31.65mm | |
| Further information | |||||
| Number of lanes | 12 | 12 | 8 | 6 | |
| Update Time | 50ms or 100ms | 50ms or 100ms | 100ms | 100ms | |
| Power Mode | Low/High | Low/High | High | Low |
* TRUGRD Lite is available only in USA and Canada. For a model comparison in the imperial system, visit this page.
** plus connector
